Label:Yes
5,Wide Application: This automatic float switch can be widely used in fishing boats, cruisers, runabouts, yachts, aquariums, small swimming pools, water reservoirs, fountains and other places that need drain the water.
4,Durable: The shell of bilge pump float switch is made of premium ABS material, sturdy and durable. The switching frequency can reach 10 million times.
3,Performance: The automatic control switch of the bilge pump is ultrasonic welding to form a closed space, which is reliable and safe, and does not leak.The switch can be removed from the base for easy cleaning, saving time and effort.
2,Use With Pumps: The bilge float switch is automatic and can be connected to various submersible pumps, bilge pumps, and water pumps. Turn the pump on when the water level reaches 2" (51mm(2.01in)) and turn off the pump when the water level reaches 3/4" (19mm(0.75in)).
1,Specification: Maximum Amps 12volts: 20A / Maximum Amps 24volts: 10A / Maximum Amps 32volts: 8A
Specifications:
Item Type: Float Switch
Material: ABS
Color: White
Size: 130* 44mm(5.12* 1.73in)
12V Working Current: 20A
24V Working Current: 10A
32VWorking Current: 8A
Line Length: 1m
Wire Gauge Size:18AWG
Package List:
1 x Float Switch
1 x User Manual
Note:
1. Keep all wire connections above the highest water level. The wires should be sealed with waterproof marine sealant to avoid corrosive of the wires
2. DC48V power supply can still be applied
